Item NO.: DF1550
Dimension: 180*150*32mm
Cross Reference NO.:
Metal Ring Material: Alloy casting iron
Rubber Ring Material: NBR(Silicone,HNBR,FKM are also available)
Hardness: 60-72HRC
Net weight:
Products Describe
| Part No. | D1 | D2 | H | d Max | D3 | D4 | t1 | t2 | t3 | α | Tol± | S | Tol± |
| DF1550 | 180 | 155 | 34 | 149 | 194 | 174 | 18.4 | 20 | 1.4 | 15 | 0.15 | 4.5 | 0.3 |
