Item NO.: DF2330
Dimension: 259*233*35mm
Cross Reference NO.:
Metal Ring Material: Alloy casting iron
Rubber Ring Material: NBR(Silicone,HNBR,FKM are also available)
Hardness: 60-72HRC
Net weight:
Products Describe
| Part No. | D1 | D2 | H | d Max | D3 | D4 | t1 | t2 | t3 | α | Tol± | S | Tol± |
| DF2330 | 259 | 233 | 35 | 225 | 280 | 250 | 17 | 18 | 2 | 15 | 0.15 | 6 | 0.5 |
