Item NO.: DF2830B
Dimension: 319*283*34mm
Cross Reference NO.:
Metal Ring Material: Alloy casting iron
Rubber Ring Material: NBR(Silicone,HNBR,FKM are also available)
Hardness: 60-72HRC
Net weight:
Products Describe
| Part No. | D1 | D2 | H | d Max | D3 | D4 | t1 | t2 | t3 | α | Tol± | S | Tol± |
| DF2830B | 319 | 283 | 34 | 278 | 329.4 | 307.3 | 18.5 | 18.5 | 1.5 | 45 | 0.15 | 2.1 | 0.5 |
