Item NO.: DO0725
Dimension: 92*72.5*35.6mm
Cross Reference NO.:
Metal Ring Material: Alloy casting iron
Rubber Ring Material: NBR(Silicone, HNBR, FKM are also available)
Hardness: 60-72HRC
Net weight:
Products Describe
| Part No. | D1 | D2 | H | d Max | D3 | D4 | D5 | t1 | t2 min | t3 | r | α | Tol± | S | Tol± |
| DO0725 | 92 | 72.5 | 35.6 | 69.5 | 96 | 95.2 | 83 | 15.2 | 20.9 | 3.5 | 4.8 | 10 | 0.1 | 3 | 0.5 |
