Item NO.: DO2200
Dimension: 239.5*220*32mm
Cross Reference NO.:
Metal Ring Material: Alloy casting iron
Rubber Ring Material: NBR(Silicone, HNBR, FKM are also available)
Hardness: 60-72HRC
Net weight: 1.027KG
Products Describe
| Part No. | D1 | D2 | H | d Max | D3 | D4 | D5 | t1 | t2 min | t3 | r | α | Tol± | S | Tol± |
| DO2200 | 239.5 | 220 | 32 | 217 | 244 | 243 | 232 | 14.5 | 16.5 | 2.8 | 5 | 10 | 0.15 | 3 | 0.5 |
