Item NO.: DO3190
Dimension: 346.5*319*46mm
Cross Reference NO.:
Metal Ring Material: Alloy casting iron
Rubber Ring Material: NBR(Silicone, HNBR, FKM are also available)
Hardness: 60-72HRC
Net weight:
Products Describe
| Part No. | D1 | D2 | H | d Max | D3 | D4 | D5 | t1 | t2 min | t3 | r | α | Tol± | S | Tol± |
| DO3190 | 346.5 | 319 | 46 | 315 | 351.6 | 350.7 | 333.7 | 18.4 | 24.1 | 3.7 | 6.3 | 10 | 0.2 | 3 | 0.5 |
