Item NO.: DO0775
Dimension: 87.6*77.5*13.6mm
Cross Reference NO.:
Metal Ring Material: Alloy casting iron
Rubber Ring Material: NBR(Silicone, HNBR, FKM are also available)
Hardness: 60-72HRC
Net weight:
Products Describe
| Part No. | D1 | D2 | H | d Max | D3 | D4 | D5 | t1 | t2 min | t3 | r | α | Tol± | S | Tol± |
| DO0775 | 87.6 | 77.5 | 13.6 | 75.9 | 90.7 | 90.2 | 89.5 | 7.5 | 8 | 1.4 | 1.5 | 15 | 0.1 | 3 | 0.5 |
